Wet Sounds Syndicate Series Marine Amplifiers represent the highest performing marine audio amplifiers on the market. With advanced technologies like Class H and Class G/H power supplies for high power with less current draw and less heat. Microprocessor controlled forced fan cooling, full polished stainless steel chassis for true marine grade, conformal coated PCB boards, advanced microprocessor protection circuit for under/over voltage, thermal overload and short protection, flexible crossovers for both high pass and low pass use on full range models, and matched power ratings to drive all Wet Sounds speakers.
The SYN2 is a high powered 2 channel class H amplifier. Because of it's class H power supply and forced fan cooling system, the SYN2 can operate at 2 ohms stereo without any heat issues typically found in conventional amplifier designs. Giving you multiple configuration capabilities. The SYN2 is matched to run tower speakers in a pair of two pairs and is also an amazing subwoofer amplifier.
Recommended Configurations:
Tower Speakers:
- (1) pair of PRO 60's or (1) pair of PRO 80's. Power: 200 x 2.
- (2) pairs of PRO 60's or (2) pairs of PRO 80's. Power: 350 x 2
- DOUBLE UP tower system: Power: 350 x 2.
Subwoofers:
- (1) XS-XXX at 4 ohms. Power: 700 x 1.
- (2) XS-10FA subwoofers at 4 ohms or (2) XS-12 subwoofers at 4 ohms. Power 700 x 1
The SYN2 is a high powered 2 channel class H amplifier. Because of it's class H power supply and forced fan cooling system, the SYN2 can operate at 2 ohms stereo without any heat issues typically found in conventional amplifier designs. Giving you multiple configuration capabilities. The SYN2 is matched to run tower speakers in a pair of two pairs and is also an amazing subwoofer amplifier.
Recommended Configurations:
Tower Speakers:
- (1) pair of PRO 60's or (1) pair of PRO 80's. Power: 200 x 2.
- (2) pairs of PRO 60's or (2) pairs of PRO 80's. Power: 350 x 2
- DOUBLE UP tower system: Power: 350 x 2.
Subwoofers:
- (1) XS-XXX at 4 ohms. Power: 700 x 1.
- (2) XS-10FA subwoofers at 4 ohms or (2) XS-12 subwoofers at 4 ohms. Power 700 x 1
Technical Specs
Stereo @ 4 Ohms | 200 x 2 watts RMS |
---|---|
Stereo @ 2 Ohms | 350 x 2 watts RMS |
Mono @ 4 Ohms | 700 x 1 watts RMS |
s/n ratio @ 1 watt | > 92 dB |
Impedance | - |
Freqency Response (Hz) | - |
Transient Distortion | < .01% @ 4 Ohms |
Input Sensitivity | 0.6 V - 6.0 V |
Input Impedance | 20K Ohms |
Bass Boost | +15 dB @ 45 Hz |
Crossover | HP/LP 55 Hz - 550 Hz |
Max Input (W) | - |
Max Output (W) | - |
Efficiency (dB/W/m) | - |
Mounting Depth (mm) | - |
Dimensions Inches ( L x W x H ) | 13" x 8" x 2 3/8" |
